This product is designed for the standard test requirements of UL, EN, IEC, etc. To reach the low pressure storage state of the sample in a short time, it can automatically control the test cycle, monitor the pressure change in the box, and realize the automatic termination of the test. Analog battery and battery in pressure equal to or lower than 11.6kPa and ambient temperature (20 ± 5) ℃ storage for 6 hours, if the battery has no leakage, no exhaust, no disintegration, no rupture and no fire, and the battery or battery after the test is not less than 90% of the voltage before the simulation experiment, that is qualified.
Technical parameter:
Internal box size | 400x 400x 400mm (width x deep x high) |
Contour size of the unit | 650x 650x1450mm (W x depth x H) |
Internal box material | SUS201 Stainless steel plate, 3.0mm thick |
External box material | 1.5mm thick cold-rolled steel sheet baking paint treatment |
Observation window | 250x250mm two layers of tempered glass with stainless steel mesh |
Pressure limit | 0.5 ~ 100 KPa, and the commonly used test pressure is 11.6 KPa |
Vacuum display | Digital-explicit vacuum table control |
Box door | Single door left open, the side of the door is equipped with an explosion-proof chain |
Calculagraph | 0-99H99, H/M / S units can be switched |
Pressure fluctuation | ≤5% |
Equipment moving | There are four universal direction casters at the bottom of the device, which can move freely |
Place content plate | Two |
Weight of equipment | 120Kg |
Source | AC220V |
Power | 1K W |
