7 inches TFT touch screen
Automatic Control
Four carbon fiber rope alternation,automatically on-off detection
Continuous evaporation,pulse evaporation two working modes
Optional rotating sample stage, TMP
Hardware/software interlock
7 inches TFT touch screen
Automatic Control
Four carbon fiber rope alternation,automatically on-off detection
Continuous evaporation,pulse evaporation two working modes
Optional rotating sample stage, TMP
Hardware/software interlock
Specification | |||
Size | 420(L)×330(D)×335(H) mm | Operation Interface | Color touch screen, digital display |
Evaporator Source | High purity carbon fiber(φ0.8mm) | No. of Evaporator source | 4 |
Evaporation Mode | Operating Mode | Auto/Manual | |
Preheat degassing | yes | Degassing Baffle | Auto |
Vacuum | Rotary pump | Pumping Speed | 1.1L/s |
Vacuum Chamber | Borosilicate glass ~φ170×130mm | Best Vacuum | ≤1Pa |
Sample Stage | ≥φ90mm | Operating Vacuum | ≤2Pa |
Power Supply | AC220V/50Hz | Rated Power | 800W |
Evaporation Source State | Automatically detect the four carbon fiber rob on-off state after power on, display in the main interface | ||
Protect Function | Vacuum protection,Over-current protection,Over-voltage protection etc. | ||
Others | Real time curve graph vacuum,current,voltage display | ||
Option | TMP(High Vacuum Mode)、Thickness Gauge、Temperature Measurement etc |
