5×8 position PLC controlled precision dip coater

    5×8 position PLC controlled precision dip coater is a multi-position precision dip coater, which can coat 5 pcs sample in one row at each time, and dip each row  of sample up to 8 position as the program to achieve multi-layer coating.

5×8 position PLC controlled precision dip coater is a precision device designed for the study of liquid phase growth films. The film is grown on the surface of the sample by moving the sample vertically in the liquid phase. The dip coating machine adopts high-precision speed control system and touch screen parameter input terminal, and realizes automatic control of 5 sample lifting coating films at the same time. The speed at which the sample enters and exits the liquid phase film material, the dwell time in the liquid phase film material, and the number of cycles in which the sample is pulled can be set by the control box.dip coater

5×8 position PLC controlled precision dip coater specifications:

Working Voltage

110/220V AC   switchable, 50/60 Hz

Max. Power Consumption

100W

Max Stroke length

65 mm

Maximum sample load

100 g

Sample Clamp & Sample Size

Sample clamp: 5 pcs included

Standard   sample size: 65mm L×25mm W×1 - 2.5 mm

Control Unit

· All parameters are controlled   by PLC via  Color Touch Screen  6"(L)×4"(W)

· Control unit is separated   from dip coating device to allow remote operation

Insertion Speed

1 - 200 mm/minute programmable by Touch   Screen PLC

Pulling Speed

1 - 200 mm/minute programmable by   Touch Screen PLC

orizontal Moving Speed

50 ~ 500 mm/minute adjustable

Speed Stability

+/- 0.05%

Immersion Container

·40 pcs pry-glass breaker (   100 ml) included with breaker holder

·Breaker size: 50mm Dia.×70 mm H ( 100 mL capacity )

Product Dimensions & Weight

·850×500×520, mm ( with frame)

·20 kg

Net Weight

18 kg (39.6 lbs)

Compliance

CE Certified

Warranty

One Year limited warranty with lifetime   support
