Laboratory 1700℃ High Temperature Muffle Furnace with 64L Chamber Capacity-CY-M1700-64L

    Application

    Muffle furnace are mainly used in metallurgy, glass, heat treatment, li-ion battery anode materials, new energy, abrasive and other industries to determine material under the condition of a certain atmosphere of professional equipment.


Featrues

1. LCD touch screen with PID Programmable control

2. CE certified, quality warranty

3. High quality alumina fiber, good heat preservation effect

4. 30 steps Programmable and SCR accuracy temperature control

5. Clear MoSi2 heating element, no color greening changing

6. Low power, energy conservation and environmental protection


Technical parmaters

ModelCY-M1700-64L
Chamber modelSide Door
DisplayLED or 7” LCD Touch Panel
Limiting temperature1700℃
Working temperature≤1600℃
Heating rateSuggestion 0~20℃/min
Temperature accuracy±1℃
Inside chamber size400*400*400(mm)
Heating elementMoSi2
Thermal coupleB Type
Temperature controlPID automatic control via SCR power control
Heating curves30 steps programmable
Chamber materialAlumina Fiber
Rated power9.5KW
Working voltageAC 380V, 50-60Hz
PackingPLY wood box
AccessoriesDoor stopper 1 pc, glove 1pair, crucible tongs 1pc, manual book
