Economic temperature control type spin coater Economic temperature control type spin coater

Economic temperature control type spin coater

    Economic temperature control type spin coater is standard with a 2-inch (50mm diameter) aluminum alloy claw turntable, which has a fast heating speed and high temperature control accuracy. Different sizes of substrates can be customized design and replaced to ensure close contact with the heating turntable.

Economic temperature control type spin coater is capable of precise temperature control of the turntable with contact heating of the substrate to achieve temperature-controlled spin coating processing at different temperatures. Using the unique invention patent rotating hot plate temperature control structure system has high temperature control precision, good repeatability, advanced technology and excellent performance.

Economic temperature control type spin coater product performance parameter:

Heating turntable: Φ50mm

Temperature control range: chamber temperature ~ 150°C

Temperature resolution: 0.1°C

Temperature control accuracy: ±0.5°C (temperature control after stabilization)

Rotating speed resolution: ±1RPM

Rotating speed range: 100-5000RPM

Acceleration range: 100-5000RPM/S

Single step setting duration: 0.1-3000S

Programmable: 100 groups of 100 steps

Automatic dispensing port: one way

Equipment weight: 15kg

Power input: AC220V, 5A

Heating power: 150W

Motor power: 200W

Disclaimer: The product introduction content (including product images, product descriptions, technical parameters, etc.) of this site is for reference only. As the update may not be timely, there will be some differences between the content and the actual situation. Please contact our sales staff to confirm. The information provided on this site does not constitute any offer or promise, and the company will not improve or modify any information on the website from time to time without prior notice.
