Auto-drying tape casting film coaters is is widely used in various high-temperature film research, such as ceramic film, crystal film, battery material film, special nano film; it can adapt to the development of film science and technology in the future under high-temperature conditions.
Main features of auto-drying tape casting film coater:
1. The coating speed can be adjusted within the range of 0-100mm / S;
2. Drying system with digital display temperature control, the maximum working temperature is 200 ℃;
3. The stroke can be adjusted by the stroke switch between 10-250mm;
4. Vacuum aluminum disk, which can quickly place or remove the substrate;
5. With adjustable film applicator;
Technical parameters of auto-drying tape casting film coater:
Coating speed | 0～100mm/s |
Maximum stroke | 250mm |
Vacuum plate | aluminum plate with vacuum |
Vacuum plate size | 365mm(L)×200mm(W)×30mm(H) |
Adjustable range of film applicator | 0.02～3.5mm |
Heating and drying system | room temperature ~ 200 ℃, digital temperature controller, accuracy ± 1 ℃ |
Power supply | 220V/50Hz |
Weight | 50KG |
Dimension | 500mm(L)×310mm(W)×330mm(H) |
Optional accessories | Micron adjustable film applicator 50-150 mm wide, width can be specified according to requirements |
